• Rating：12VDC 50mA
• Contact Resistance：100mΩ MAX Initial
• Insulation Resistance ：100mΩ min. 100VDC
• Dielectric Strength：250VAC(50/60Hz)FOR 1MIN
• Operating Force：180gf 260gf
• Travel：0.25mm
• Life：100,000~300,000 cycles
• Operating Temperature：-30℃ ~80℃
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Travel | Life | Operating Temperature | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| R11-2428 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 180gf 260gf | 0.25mm | 100,000~300,000 cycles | -30℃ ~80℃ | 暫無 |
| R11-2630 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 180gf 260gf | 0.25mm | 100,000~300,000 cycles | -30℃ ~80℃ | 暫無 |
| R11-2616 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 180gf 260gf | 0.25mm | 100,000~300,000 cycles | -30℃ ~80℃ | 暫無 |
| R11-2030 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 180gf 260gf | 0.25mm | 100,000~300,000 cycles | -30℃ ~80℃ | 暫無 |
| R11-3131 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 180gf 260gf | 0.25mm | 100,000~300,000 cycles | -30℃ ~80℃ | 暫無 |
| R11-3131A | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 180gf 260gf | 0.25mm | 100,000~300,000 cycles | -30℃ ~80℃ | 暫無 |
| R11-3738 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 180gf 260gf | 0.25mm | 100,000~300,000 cycles | -30℃ ~80℃ | 暫無 |
| R11-4545 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 180gf 260gf | 0.25mm | 100,000~300,000 cycles | -30℃ ~80℃ | 暫無 |
| R11-4836 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 180gf 260gf | 0.25mm | 100,000~300,000 cycles | -30℃ ~80℃ | 暫無 |
| R11-4827 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 180gf 260gf | 0.25mm | 100,000~300,000 cycles | -30℃ ~80℃ | 暫無 |
| R11-74073 | 12VDC 50mA | 100mΩ MAX Initial | 100mΩ min. 100VDC | 250VAC(50/60Hz)FOR 1MIN | 180gf 260gf | 0.25mm | 100,000~300,000 cycles | -30℃ ~80℃ | 暫無 |
